一、 Description
       The current transformer of the type LMZB6 - 10 is type product. It is used for metering electric energy and rated frequency 50Hz or 60Hz and rated voltage lOkV.
二. Type designation

三、 Construction
    This current transformer is casting resin insulated, fully enclosed and busbar type. There is electric scroll with bioelectric potential wires in the bus hole.  When be installed, connecting the bioelectric potential wires with the busbar. There are four mounting holes on the casting board.
四、Technical data
    1、rated insulation level：12/42/75kV
    2、rated secondary current：5A
    3、 Rated primary current, accuracy classes combination,ated output see form
